Distech
Products > Controls
Overview
Distech Controls offers an extensive line of quality, feature-rich HVAC controllers for BACnet® and LONWORKS® designed for dependable long-term performance.
Our HVAC controllers are based on a robust common hardware platform and share the same programming and productivity enhancing toolset, providing increased efficiency and options for system design, installation, service, and maintenance.
ECB-VAV
Pre-engineered configurable application selected from the EC-Smart-Vue communicating sensor or from EC-NetAX configuration pages for quick setup, On-board drift-free and zero calibrated flow sensor reducing air flow balancing time, Built-in brushless DC motor actuator with intelligent damper control algorithm for extended actuator lifecycle and fast air flow balancing, 5 models to cost effectively address all VAV applications, Universal inputs and outputs for maximum installation flexibility, Built-in brushless DC motor actuator with intelligent damper control algorithm, Digital outputs (TRIAC) that support internal supply of 24 VAC, simplifying wiring of outputs such as floating actuators, 15 VDC power supply to power 4-20mA transducers, 1 calendar, 2 schedule, 8 loop (PID), and over 200 BACnet objects, Support of up to 4 Allure series communicating sensors, Open-to-Wireless™ Solution: support of up to 18 wireless battery-less inputs, The ECB-VAV model supports the Smart Room Control Solution.
ECB-103
4 universal inputs
4 digital outputs (TRIAC) that supports internal supply of 24 VAC, simplifying wiring of outputs such as floating actuators
2 universal outputs
15 VDC power supply to power 4-20mA transducers
1 calendar, 2 schedule, 8 loop (PID), and over 200 BACnet objects
Support up to 4 Allure series communicating sensor
Open-to-Wireless™ Solution: support of up to 18 wireless battery-less inputs
ECB-253
6 universal inputs
5 digital outputs (TRIAC)
3 universal outputs
15 VDC power supply to power 4-20mA transducers such as duct static pressure, etc.
1 calendar, 2 schedule, 8 loop (PID), and over 200 BACnet objects
Some models available with environmental protection
ECB-253 includes live graphics color display (integrated LCD operator interface)
Support up to 4 Allure series communicating sensors
Open-to-Wireless™ Solution: support of up to 18 wireless battery-less inputs
ECB-350
10 universal inputs including 4 for fast pulse counting and metering applications
8 universal outputs
15 VDC power supply to power 4-20mA transducers
2 calendar, 10 schedule, 30 loop (PID), and over 300 BACnet objects
Internal alarm functionality
ECB-350 includes live graphics color display (integrated LCD operator interface)
Support up to 12 Allure series communicating sensors
Open-to-Wireless™ Solution: support of up to 28 wireless battery-less inputs
ECB-450
12 universal inputs including 4 for fast pulse counting and metering applications
12 universal outputs (ECB-400 Series), 8 digital outputs (TRIAC), and 4 universal outputs (ECB-403 Series)
Optional HOA switch with potentiometer to locally override and monitor overridden outputs
15 VDC power supply to power 4-20mA transducers
2 calendar, 10 schedule, 30 loop (PID), and over 300 BACnet objects
Internal alarm functionality
ECB-450 and ECB-453 include live graphics color display (integrated LCD operator interface)
Support up to 12 Allure series communicating sensors
Open-to-Wireless™ Solution: support of up to 28 wireless battery-less inputs
ECB-650
16 universal inputs including 4 for fast pulse counting and metering applications
Expandable I/O capabilities with up to 2 ECx modules for a total of 40 inputs and 36 outputs
Optional HOA switch with potentiometer to locally override and monitor overridden outputs
15 VDC power supply to power 4-20mA transducers
2 calendar, 10 schedule, 30 loop (PID), and over 300 BACnet objects
Internal alarm functionality
ECB-650 includes live graphics color display (integrated LCD operator interface)
Support up to 12 Allure series communicating sensors
Open-to-Wireless™ Solution: support of up to 28 wireless battery-less inputs
