Danfoss
Products > VSD's
VLT® Micro Drive FC 51
Maximum strength with reduced installation costs
The VLT® Micro Drive FC 51 is small and yet powerful and built to last. Panel space can be saved and installation costs reduced thanks to its compact size and minimal commissioning requirements.
Despite its compact size and easy commissioning, the VLT Micro Drive can be set up to perform perfectly even in complex applications. It is supported by guided programming of specific functions and the use of a PC software tool for parameterizing. And, thanks to its coated PCBs, the drive ensures reliable and cost-effective operation also in demanding environments.
Supply voltages and power range
1 x 200-240 V...0.18-2.2 kW
3 x 200-240 V...0.25-3.7 kW
3 x 380-480 V..0.37-22 kW
Features and benefits
Side-by-side mounting without derating is possible thanks to the compact, book-style designPenetration of dust is minimized thanks to coated PCBsRadio disturbance from motor cables is limited due to built-in RFI filtersLifetime of the drive is extended and reliability improved as a result of the effective heat sink that removes heat from the electronicsEnergy consumption can be reduced as kinetic energy in the application can be transformed into braking power to slow down the motor
Applications
Conveyors, pumps, fans, mixers, extruders, palletizers, packaging machines and other industrial appliances.
VLT® HVAC Basic Drive FC 101
Efficient, basic control of fans and pumps in HVAC applications
Optimized for basic operation of pumps and fans, the VLT® HVAC Basic Drive is supplied with built-in functions that reduce initial costs and increase productivity.
Overview
The drive is the most compact unit in its class. Integrated DC coils reduce harmonics to an absolute minimum, and the Automatic Energy Optimizer saves 15-25% energy from the second you turn the it on. Achieve the lowest cost of ownership with a premier drive dedicated to ventilation, heating, and refrigeration applications.
Range
3 x 200 – 240 V............ 0.25 – 45 kW
3 x 380 – 480 V............ 0.37 – 90 kW
3 x 525 – 600 V............ 2.2 – 90 kW
Features and Benefits
Easy to configure
Start up with a configuration wizard Easy to program parameters Alphanumeric display Hand – Off – Auto keys Status LCDs Easy to install Easy to wire up 7 languages and numeric programming
All built-in – low investment
Flying Start: Reduced mechanical wear on equipmentMost common HVAC protocols for BMS controller connectivity are embedded: Less extra gateway solutions neededBuilt-in PI controllerSmart Logic Controller (Often makes PLC unnecessary)Integrated fan, pump functionalityFire Override Mode for enhanced safety
Save energy – less operation cost
Automatic Energy Optimizer function Saves 5 – 15% energySleep mode Energy saving and extends lifetimeUnique cooling concept with no forced air flow over electronicsMax ambient temp. 50° C: no external cooling
Built-in DC coils – no harmonic concerns
Category C1 filters: meets protection class C1, C2 and C3Integrated DC Choke Small power cables. Meets EN 61000-3-12Thermistor input: prevents overheat of motorrs, extruders, palletizers, packaging machines and other industrial appliances.
Enhanced VLT® HVAC Drive FC 102
Get even more drive in your HVAC – with rock-bottom lifecycle costs in any climate
Get even higher reliability and lower total cost of ownership (TCO) in your heating, ventilation and air-conditioning (HVAC) installations, with this unique VSD optimized for building automation systems.
More than ever, the extreme climates, inaccessible machine rooms and isolated outposts of our planet need the best process control there is for their HVAC installations. Your everyday critical functions and costly systems need it too, as they face ever-increasing competition and efficiency demands. Always with high performance in mind, the enhanced VLT® HVAC Drive gives you more room to maneuver. It confronts the issues and gives you rock-solid reliability. With rock-bottom lifecycle costs too.
Supply voltages and power range
3 x 200-240 V...............................1.1-45 kW
3 x 380-480 V..........................1.1-1000 kW
3 x 525-600 V..............................1.1-90 kW
3 x 525-690 V...........................1.1-1400 kW
Low harmonic drive
3 x 380-480 V...132-710 kW
12-pulse drive
3 x 380-500 V...250-1000 kW
3 x 525-690 V...250-1400 kW
Features and benefits
Slim down your TCO. Ongoing demands for lower TCO are challenges the VLT® HVAC Drive can help you meet. Install it outdoors in extreme climates. Searing heat and deep frost are all in a day’s work for the enhanced VLT® HVAC Drive. You get full reliability running this drive outdoors with temperature extremes from 50°C to minus 25°C. Control multiple IE5 PM motors. Bring energy efficiency to a new level in your fan and pump applications. You can even control multiple IE5 permanent magnet (PM) motors using only a single drive. Save time. You can parameterize and troubleshoot the drive from outside the AHU, thanks to the remote LCP. Maximize uptime by reducing the shutdown, since there is no need to open up the AHU and lock it down again afterwards.Get the freedom to choose your favorite motor. Choose exactly the motor you prefer, for whatever reason from supply security to performance optimization. The enhanced VLT® HVAC Drive is not only optimized to control induction, permanent magnet and synchronous reluctance motor technologies; our development team is working all the time to include compatibility with upcoming motor technologies in future software updates as well. Get the freedom to communicate. The ability to integrate the AC drive easily into your building automation system is a key to optimal control. The VLT® HVAC Drive features a number of HVAC-specific communication protocols, such as BACnet/IP, that give you flexibility of installation in both new and existing building automation systems.
Applications
Pumps, fans, compressors.
